 / Maniron 340-3800MHz RF Directional Coupler -160dBc

Low PIM 300W Directional Coupler with 4.3-10 connector
Low PIM 300W Directional Coupler with 4.3-10 connector Low PIM 300W Directional Coupler with 4.3-10 connector Low PIM 300W Directional Coupler with 4.3-10 connector

Maniron 340-3800MHz RF Directional Coupler -160dBc

RF Directional Coupler covers wide frequency band from 340-3800MHz,which has different coupling like 6dB 10dB 15dB 20dB,it is in low PIM.

  • Item NO.:

    MDC-3438-xx-160

  • Product Orgin:

    China

  • Brand:

    Maniron

  • Shipping Port:

    Shanghai/Shenzhen

  • Color:

    Black
Inquiry now
  • Products Details

Product Name

340-3800MHz Low PIM -160dBc Directional Coupler


Product Features

◆ with Wide Frequency Band

◆ 2G/3G/4G/LTE Coverage

◆ Low VSWR/Low PIM

◆ High power with 300W

◆ Widely used for In-building Solutions


RF Directional Coupleris used for DAS IBS,which covers wide band frequency and different couplings.We can reach Low PIM -160dBc.It can be customized according to customers' requirements.


Specification

Freq(MHz)
340 -3800
Coupling(dB)
5
6
7
8
10
13
15
20
30
IL(dB)
≤2.5
≤1.8
≤1.5
≤1.2
≤1.1
≤0.8
≤0.7
≤0.5
≤0.3
Isolation(dB)
≥23
≥24
≥25
≥26
≥28
≥30
≥32
≥35
≥45
VSWR
≤1.30
≤1.30
 ≤1.30
 ≤1.30
 ≤1.30
 ≤1.30
 ≤1.30
 ≤1.30
 ≤1.30
PIM(dBc)
≤-160dBc@2*43dBm
Power(W)
300 (average)
Impedance
50 ohm
Connector
4.3-10 F
Color
Black

Images


Leave Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
