Product Name
5W RF Attenuator (DC-6GHz, 4.3/10-male to 4.3/10-female)
Product Features
◆ Wide Frequency Band DC-6GHz
◆ Low VSWR
◆Low Attenuation Accuracy
◆ Widely used for In-building Solutions
Technical &Mechanical Specifications
|
Model No. |
MA-5-6-XX-43/MF(XX means attenuation in dB) |
|||||||||
|
Freq(MHz) |
DC-6GHz |
|||||||||
|
VSWR |
≤1.30 |
|||||||||
|
Power(W) |
5 (average) |
|||||||||
|
Attenuation(dB) |
3 |
4 |
5 |
6 |
8 |
9 |
10 |
15 |
20 |
30 |
|
Accuracy(dB) |
±0.5 |
±0.5 |
±0.5 |
±0.5 |
±0.6 |
±0.6 |
±0.8 |
±1.0 |
±1.2 |
±1.5 |
|
Impedance |
50 ohm |
|||||||||
|
Connector |
4.3/10-male to 4.3/10-female |
|||||||||
|
Color |
Black |
|||||||||
|
Temp(deg) |
-30~+65 |
|||||||||
|
Weight(kg) |
0.12 |
|||||||||
Mechanical Drawing
