Maniron DC-6GHz 20W RF Attenuator with SMA-Male to Female

DC-6GHz 20W RF Attenuator is in low VSWR and it's with SMA-M to SMA-F
  • Item NO.:

    MA-20-6-XX-S
  • Product Orgin:

    China
  • Brand:

    Maniron
  • Shipping Port:

    Shanghai/Shenzhen/Ningbo
  • Color:

    Black
  • Products Details

Product Name

20W DC-6GHz Coaxial Attenuator with SMA-connector


Product Features

◆ Wide Frequency Band DC-6Hz

◆ High Power up to 20W

◆ Low VSWR

◆Low Attenuation Accuracy

◆ Widely used for In-building Solutions

RF coaxial attenuator covers freq. DC to 6GHz,which is in low VSWR.Its widely used for IBS,Distrinuted Antenna System


Technical &Mechanical Specifications

Freq(MHz)

                                  DC-6GHz

Attenuation(dB)

3

6
10
15
20
30
Accuracy(dB)
±0.6
±0.6

±0.8

±1.0
±1.2
±1.5
VSWR
≤1.30
Average Power(W)
20
Impedance
50 ohm
Connector
SMA-M to SMA-F
Color
Black
Ambient Temp(deg)
-55~+100
Dimensions(mm)
38*38*94 (Connectors Included)

Note:All specification can be customized according to customers' requirements.

dc-6ghz rf attenuator

Our Advantages

Hefei Maniron Electronic And Technology Co.,Ltd.,established in 2002,located in Hefei National Hi-tech Industry Development Zone,is a leading manufacture of RF Components.
OEM services are offered.
Maniron has a huge fellowship that is composed of many high-level technologists.
We also has established a Research Insititution which is a cooperating with some famous universties in China.

varies style, high quality, reasonable price and good service

Excelent engineers and profesional team

Full range of passives for 5G, frequency can be 380-6000MHz

Low PIM -165dBc is also our main advantage




Leave Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
