8-way power splitter 617-3980MHz with NEX10-K type connector

8 Ways Wilkinson Power Splitter 617-3980MHz with NEX10 connector

Item NO.:
MPS-740-08-NEX10
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Shenzhen/Guangzhou/Ningbo
Color:
Gray

Inquiry now

Products Details

Product Name:

8-way Power Splitter with Nex10 connector

Product Features:

◆ Wide Frequency Band 617-3980MHz

◆ 2G/3G/4G/LTE Coverage

◆ Low Insertion Loss

◆ Low VSWR

◆ Widely used for In-building Solutions

Technical & Mechanical Specifications

Model No.	MPS-740-08-NEX10
Frequency	617~3980MHz
Insertion Loss	≤11.0dB including split loss）
Inband ripple	≤1.5dB
Return loss	≤-15dB
3rd Order PIM	COM PORT：≤-145dBc@43dBm×2 ANT1-ANT8 PORT：≤-145dBc@37dBm×2
5th order PIM	COM PORT：≤-155dBc@43dBm×2 ANT1-ANT8 PORT：≤-155dBc@37dBm×2
Impedance	50 ohm
Connector	NEX10-female
Surface Finishing	conductive oxidation
Power rate	1.COM：45W(average)，450W(peak) 2.ANT1-ANT8：5W(average)，50W(peak)

Mechanical Drawing:
