RF 698-3800MHz 4way Wilkinson Power Divider

RF 2way/3way/4way Wilkinson/Microstrip Power Splitter divider has wide frequency band 698-3800MHz,which is widely used for 5G Market.It has low PIM Value,low insertion loss and VSWR

Item NO.:
MWPS-738-04-4F-153
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Shenzhen/Guangzhou
Color:
Gray/Customized
MOQ:
5

Inquiry now

Products Details

Product Name

RF 698-3800MHz 4way Wilkinson Power Divider.These new designs with Low PIM -153dBc are used for 5G market.

Product Features

◆ Low VSWR

◆ Low Insertion Loss

◆ Indoor or outdoor Application

◆PIM-153dBc@2*43dBm

◆ Widely used for In-building Solutions and Outdoor application.

Technical &Mechanical Specifications

Model No.	MWPS-738-02-4F-153	MWPS-738-03-4F-153	MWPS-738-04-4F-153
Freq(MHz)	698-3800
Split Loss(dB)	3.0	4.8	6.0
Insertion Loss(dB)	≤0.8	≤1.0	≤1.0
Isolation(dB)	≥18	≥16	≥16
VSWR	≤1.4	≤1.45	≤1.45
Return Loss(dB)	≥16	≥15	≥15
PIM (dBc)	≤-153dBc@2*43dBm (698-2700)
Power(W)	50(average)
Impedance	50 ohm
Connector	4.3/10-female
Color	Silver-plated/Black/Customized
Temp(deg)	-30~+70
Application	Indoor or Outdoor, IP65

Product image
