Product Description
The 150-174MHz RF Combiner (also known as a VHF/UHF Combiner) is a high-efficiency passive component designed to merge VHF and UHF signals into a single output. With a robust IP67 waterproof rating, it is engineered for both indoor and outdoor applications, providing low VSWR and high reliability for mission-critical communication networks.
Product Features
- Multi-Band Coverage: Seamlessly integrates 150-174MHz and 403-512MHz frequencies for versatile network coverage.
- IP67 Protection: Fully sealed design suitable for harsh outdoor environments and In-building Solutions (IBS).
- High Power Handling: Supports up to 500W Peak Power, ensuring durability under high-stress signal loads.
- Customizable: All technical specifications can be adjusted to meet your specific project requirements.
Technical Specifications
| Model No. | MNC-150-174 / 403-512-NF |
| Frequency Port 1 | VHF: 150 - 174 MHz |
| Frequency Port 2 | UHF: 403 - 512 MHz |
| Isolation | 50 dB |
| VSWR | ≤ 1.4 |
| Power Handling | 20W (Avg) / 500W (Peak) |
| Connector Type | N-Female |
| Protection Class | Indoor / Outdoor IP67 |
| Housing Color | Red (Customizable) |
| Impedance | 50 Ω |
NOTE: All specifications, including frequency range, isolation levels, and housing color, can be fully customized according to your project requirements.
Frequently Asked Questions
- Q1: Can this combiner be used outdoors in rainy conditions?
- A: Yes, it features an IP67 rating, which means it is completely protected against dust and can withstand temporary immersion in water, making it ideal for outdoor base stations.
- Q2: What is the main function of this VHF/UHF combiner?
- A: It allows you to combine signals from two different frequency bands (VHF 150-174MHz and UHF 403-512MHz) into a single antenna system, reducing cable costs and installation complexity.
- Q3: Do you provide OEM services for specific color coding or branding?
- A: Absolutely. While the standard color is Red, we provide OEM services and can customize the appearance and branding to match your company's standards.
- Q4: How can I reach technical support for custom inquiries?
- A: Our sales and engineering teams are available 24 hours a day. We are committed to providing professional skill support for any custom RF solution you need.
