Maniron Multicoupler N type Connector 400MHz Transceiver

Maniron Multicoupler N type Connector 400MHz Transceiver Multiplexer,Wide Frequency Band,Low Noise Figure,Low VSWR,High Port to Port Isolation,worth a shot.
  • Item NO.:

    MN-TC-400M
  • Lead Time:

    as per your Detaield QTY
  • Product Orgin:

    Anhui,China
  • Brand:

    Maniron
  • Shipping Port:

    Shenzhen,shanghai
  • Color:

    Black
  • MOQ:

    5
  • Products Details

Product Description

The Maniron Multicoupler 400MHz is a high-precision RF Transceiver Multiplexer designed for dual-band operations. It features adjustable total gain (3-15dB) and a low noise figure, making it an essential component for complex signal management.

Application Scenarios

  • RF Distribution Systems: Efficiently multiplexing transceiver signals in multi-channel communication hubs.
  • Base Station Integration: Ideal for 400MHz band infrastructure requiring high port-to-port isolation.
  • Signal Amplification: Providing adjustable gain control for Rx1 and Rx2 frequencies in low-signal environments.

Technical Specifications

Model No. MN-TC-400M
Frequency (MHz) Rx1: 486.0125 / Rx2: 487.7625
Noise Figure ≤3.5 (dB)
Total Gain 3~15 (dB) Adjustable
Power +12V
Working Current ≤250mA
Adjacent Isolation ≥20dB
VSWR 1.25
Impedance(Ω) 50

NOTE: All specifications can be modified according to customer requirements. We provide professional customization for various RF frequencies.

Frequently Asked Questions

Q1: Can the Rx1 and Rx2 frequencies be customized for our network?
A: Yes, we offer OEM services and can adjust the multicoupler to support your specific frequency bands.
Q2: What are the power requirements for this multiplexer?
A: This model operates on a standard +12V power supply with a working current of ≤250mA.
Q3: How do I adjust the total gain for the system?
A: The gain is adjustable from 3 to 15dB. Our engineers can provide technical support to help you tune the system for optimal performance.
Q4: Is technical support available for integration?
A: Absolutely. We offer 24-hour engineer support to assist with any technical inquiries or integration challenges.
