High Quality DC-3GHz 400W N male to N Female Lightning Arrestor

The Gas-tube Arrestor covers frequency from DC to 3GHz with N Male to N Female Connector
  • Item NO.:

    MLA-3-NMF
  • Product Orgin:

    China
  • Brand:

    Maniron
  • Shipping Port:

    Shanghai/Shenzhen/Ningbo
  • Color:

    Silver
  • Products Details

Product Name

DC-3GHz Lighting Arrestor with N male to N Female connector


Product Features

◆ Wide Frequency Band

◆ 2G/3G/4G/LTE Coverage

◆ Low VSWR

◆Easily Replaced Gas Tube Element

◆Multi-Strike Capability

It is Surge Protector which is Designed for antenna coaxial device and receive/transmit system not to be spoiled by lightning over-voltage, induced over-voltage and static discharge..It's in wide frequency.And it can be customized according to customers' requirements.


Technical &Mechanical Specifications


Frequency
DC-3GHz
VSWR
≤1.2
Transmission Power
400W
Dielectric Withstanding Voltage
≥2500V RMS, 50hz at sea level
Working Voltage
≤1000V RMS, 50hz at sea level
Rated DC Voltage
≤230V
Impedance
50ohm
Connector
N-M to N-F

Pictures

DC-3GHz Lightning Arrestor
