Product Overview
The 340-2700MHz Power Tapper is specifically engineered for Public Safety Systems and critical communications infrastructure. It supports a wide frequency range from 340MHz up to 2700MHz, ensuring compatibility with UHF, 700/800MHz, and cellular bands. Built with 200W power handling and an IP65 waterproof rating, this component provides high reliability for both indoor and outdoor life-safety network deployments.
Technical & Mechanical Specifications
| Electrical | Frequency Range | 340-617 / 617-960 / 1700-2700 MHz |
| Impedance / PIM | 50Ω / No PIM Rated | |
| Average Power | 200W | |
| Mechanical | IP Grade / Application | IP65 / Indoor & Outdoor |
| Connector Type | N-Female | |
| Housing Material | Aluminum | |
| Color | 200C Red | |
| Temperature Range | -35° C to +75° C |
Detailed Model Parameters
| Model Number | Ratio (nom) | Coupling Value (dB) | Coupling Accuracy (dB) | Input VSWR (max) | Average Power (W) | Mainline Loss (Min) | Mainline Loss (Max) |
|---|---|---|---|---|---|---|---|
| MN-PT-3427-3-NF | 2:1 / 3.0dB | 4.8 |
-2.0/+0.5@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 1.4 | 3.10 |
| MN-PT-3427-5-NF | 3:1 / 4.8dB | 6.1 |
-1.8/+0.7@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.99 | 2.50 |
| MN-PT-3427-6-NF | 4:1 / 6.0dB | 7.0 |
-1.8/+0.7@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.75 | 1.75 |
| MN-PT-3427-7-NF | 4:1 / 7.0dB | 7.8 |
-1.8/+0.7@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.65 | 1.45 |
| MN-PT-3427-8-NF | 6:1 / 8.0dB | 8.5 |
-1.8/+0.7@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.45 | 1.40 |
| MN-PT-3427-10-NF | 10:1 / 10dB | 10.5 |
±1.2@340-617MHz ±1.0@617-960MHz ±1.0@1700-2700MHz |
1.30 | 200 | 0.20 | 0.80 |
| MN-PT-3427-13-NF | 10:1 / 13dB | 13.0 |
±1.3@340-617MHz ±1.25@617-960MHz ±1.25@1700-2700MHz |
1.30 | 200 | 0.13 | 0.80 |
| MN-PT-3427-15-NF | 30:1 / 15dB | 15.3 |
±1.3@340-617MHz ±1.25@617-960MHz ±1.25@1700-2700MHz |
1.30 | 200 | 0.01 | 0.45 |
| MN-PT-3427-20-NF | 100:1 / 20dB | 20.1 |
±1.6@340-617MHz ±1.5@617-960MHz ±1.5@1700-2700MHz |
1.30 | 200 | 0.01 | 0.40 |
| MN-PT-3427-30-NF | 1000:1 / 30dB | 30.1 |
±2.15@340-617MHz ±2.0@617-960MHz ±2.0@1700-2700MHz |
1.30 | 200 | 0.01 | 0.35 |
Frequently Asked Questions
- Q1: What is the primary use of this 340-2700MHz Power Tapper?
- A: It is designed for Public Safety Systems, ensuring critical signal distribution across VHF/UHF and cellular bands for first responders.
- Q2: Does the "200C Red" color serve a technical purpose?
- A: The red finish is the industry standard for emergency infrastructure, allowing technicians to easily differentiate public safety hardware from commercial DAS components.
