Product Overview
The 698-2700MHz Power Tapper is a high-performance RF component designed for precise signal distribution in IBS, BTS, and DAS infrastructure. Engineered for 2G, 3G, and 4G/LTE networks, it handles up to 200W average power. The rugged IP65-rated aluminum housing ensures reliable operation in both indoor and outdoor environments.
Technical & Mechanical Specifications
| Category | Parameter | Specifications |
| Electrical | Frequency Range | 698-2700 MHz |
| Impedance | 50Ω nominal | |
| PIM (dBc @ 2*43dBm) | No PIM Rated | |
| Mechanical | IP Grade / Application | IP65 / Indoor & Outdoor |
| Temperature Range | -35° C to +75° C | |
| Connector Type | N-Female | |
| Housing Material | Aluminum (Black) | |
| Average Power | 200W |
Detailed Model Parameters
| Model Number | Ratio (nom) | Coupling (dB) | Coupling Accuracy (dB) | Input VSWR | Power (W) | Mainline Loss (Min) | Mainline Loss (Max) |
|---|---|---|---|---|---|---|---|
| MN-PT-3427-3-NF | 2:1/3.0dB | 4.8 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 1.4 | 3.10 |
| MN-PT-3427-5-NF | 3:1/4.8dB | 6.1 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.99 | 2.50 |
| MN-PT-3427-6-NF | 4:1/6.0dB | 7.0 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.75 | 1.75 |
| MN-PT-3427-7-NF | 4:1/7.0dB | 7.8 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.65 | 1.45 |
| MN-PT-3427-8-NF | 6:1/8.0dB | 8.5 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.35 | 200 | 0.45 | 1.40 |
| MN-PT-3427-10-NF | 10:1/10dB | 10.5 |
±1.0@698-960MHz ±1.0@1700-2700MHz |
1.30 | 200 | 0.20 | 0.80 |
| MN-PT-3427-13-NF | 10:1/13dB | 13.0 |
±1.3@340-617MHz ±1.25@617-960MHz ±1.25@1700-2700MHz |
1.30 | 200 | 0.13 | 0.80 |
| MN-PT-3427-15-NF | 30:1/15dB | 15.3 |
±1.25@698-960MHz ±1.25@1700-2700MHz |
1.30 | 200 | 0.01 | 0.45 |
| MN-PT-3427-20-NF | 100:1/20dB | 20.1 |
±1.5@698-960MHz ±1.5@1700-2700MHz |
1.30 | 200 | 0.01 | 0.40 |
| MN-PT-3427-30-NF | 1000:1/30dB | 30.1 |
±2.0@698-960MHz ±2.0@1700-2700MHz |
1.30 | 200 | 0.01 | 0.35 |
Frequently Asked Questions
- Q1: What frequency bands does this Power Tapper support?
- A: It supports a wide frequency range from 698MHz to 2700MHz, covering all major cellular bands including LTE, 3G, and 2G.
- Q2: Can I use this device for outdoor DAS installations?
- A: Yes. The device is IP65 rated, meaning it is waterproof and dustproof, making it perfectly suitable for both indoor and outdoor applications.
Product Detail Images
