5G Low PIM Power tapper 600-6000MHz

5G power tapper 600-6000MHz, 3dB/5dB/6dB/7dB/8dB/10dB/13dB/15dB/20dB/30dB, Low PIM, VSWR and insertion loss
  • Item NO.:

    MNL-PT-XXdB-4F-161dB
  • Product Orgin:

    China
  • Shipping Port:

    Shanghai/NingBo/Shenzhen
  • Color:

    Grey, Black or customized
  • Products Details

Product name:

5G Power tapper 600-6000MHz, Low PIM , N type


Product features:

Low Insertion Loss

Low VSWR

Low Passive Intermodulation

Up to 200W Average Power

High Reliability, IP65


Technical and Mechanical Specification:

Model No.

MNL-PT-XXdB-4F-161dBc

Freq(MHz)

600-960 MHz &1710-2700 MHz&3400-3800 MHz&5100-5850 MHz

Ratio.nom

2:1/3dB

3:1/4.8dB

4:1/6dB

6:1/8dB

10:1/10dB

20:1/3dB

30:1/15dB

100:1/20dB

1000:1/30dB

Coupling Values(dB)

4.8

6

7

8

10

13

15

20

30

Coupling(dB)

5100-5850 MHz

4.8 dB

±1.3 dB

5.8dB

±1.2dB

6.8 dB

±1.2 dB

8.0 dB

±1.2 dB

10.2 dB

±1.3 dB

13.2 dB

±1.4 dB

15.1 dB

±1.5dB

20.1 dB

±1.5 dB

30.1 dB

±1.5 dB

Coupling(dB)

3400-3800 MHz

4.8 dB

±1.3 dB

5.8dB

±1.2dB

6.8 dB

±1.2 dB

8.0 dB

±1.2 dB

10.2 dB

±1.3 dB

13.2 dB

±1.4 dB

15.1 dB

±1.5dB

20.1 dB

±1.5 dB

30.1 dB

±1.5 dB

Coupling(dB)

2170-2700 MHz

5.0 dB

±1.3 dB

6.3 dB

±1.2dB

7.2 dB

±1.2 dB

8.2 dB

±1.2 dB

10.2dB

±1.2 dB

13.2 dB

±1.4 dB

15.1 dB

±1.5dB

20.1 dB

±1.5 dB

30.1 dB

±1.5 dB

Coupling(dB)

600-960MHz

5.3 dB

±1.5 dB

6.3 dB

±1.3dB

7.3 dB

±1.3 dB

8.3 dB

±1.2 dB

10.3dB

±1.3 dB

13.2 dB

±1.4 dB

15.2dB

±1.5dB

20.2dB

±1.5 dB

30.2dB

±1.5 dB

Coupled loss

2.1 dB

1.35dB

1.0 dB

0.9dB

0.45dB

0.14dB

0.05dB

0.05dB

0.05dB

Dissapative Loss(dB)

0.35dB

0.35dB

0.35dB

0.35dB

0.35dB

0.35dB

0.35dB

0.35dB

0.35dB

Splitting ratio

1:0.33 :

0.67

1:0.25 :0.75

1: 0.2 :

0.8

1:0.16 :0.84

1 : 0.1

: 0.9

1: 0.05

: 0.95

1: 0.03

: 0.97

1: 0.01

: 0.99

1: 0.01

: 0.99

InputVSWR max

1.50

1.50

1.45

1.45

1.45

1.40

1.40

1.40

1.40

PIM(dBc)

≤ -161dBc @700-2700MHz

Average Power(W)

Average Power 300W (CW)

Impedance (ohm)

50

Connector

4.3-10 Female

Color

Black

Working Temperature (deg)

-35~+65

Application

Indoor &Outdoor, IP65

Relative Humidity

5%-95%


OUR SERVICES


1. Professional skills support for 600-6000MHz Low PIM-160dBc power tapper
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.

NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose
