Product Name
300-5850MHzRF Power Tapper with N-Female
RF Power Tapper is in Low PIM -161dBc,with Low VSWR and Low Insertion Loss
RF Tapperis widely used for Distributed Antenna System and In-building Solutions,it is waterproof IP65.
Technical &Mechanical Specifications
|
Freq(MHz)
|
380-960 MHz & 1710-2700 MHz& 3400-3800 MHz& 5100-5850 MHz
|
||||||||
|
Coupling Values(dB)
|
4.8 |
6 |
7 |
8 |
10 |
13 |
15 |
20 |
30 |
|
Coupling(dB) |
4.8 dB±1.3 dB |
5.8dB±1.2dB |
6.8 dB±1.2 dB |
8.0 dB±1.2 dB |
10.2 dB±1.3 dB |
13.2 dB±1.4 dB |
15.1 dB±1.5dB |
20.1 dB±1.5 dB |
30.1 dB±1.5 dB |
|
Coupled loss
|
2.1 dB
|
1.35dB
|
1.0 dB
|
0.9dB
|
0.45dB
|
0.14dB
|
0.05dB
|
0.05dB
|
0.05dB
|
|
Dissapative
Loss(dB)
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
0.35dB
|
|
Splitting ratio
|
1:0.33 :
0.67
|
1:0.25 :
0.75
|
1: 0.2 :
0.8
|
1:0.16 :
0.84
|
1 : 0.1
: 0.9
|
1: 0.05
: 0.95
|
1: 0.03
: 0.97
|
1: 0.01
: 0.99
|
1: 0.01
: 0.99
|
|
Input VSWR max
|
1.50
|
1.50
|
1.45
|
1.45
|
1.45
|
1.40
|
1.40
|
1.40
|
1.40
|
|
PIM(dBc)
|
≤ -161dBc @ 700-2700MHz
|
|
|
||||||
|
Average Power(W)
|
300W
|
||||||||
|
Connector
|
4.3-10 Female
|
||||||||
