Product Name
450-4000 MHz power tapper with 4.3-10-Female connector,widely for telecommunication
Product Features
◆ Wide Frequency Band
◆ 2G/3G/4G/LTE/5G Coverage
◆ Low Passive Intermodulation
◆ Low VSWR & Insertion Loss
◆ High Isolation, Indoor & Outdoor
Technical & Mechanical Specifications
|
Item |
Specification |
||||||||||
|
Model |
MNL-PT-4540-4F-160-XX(XX refers to couplings) |
||||||||||
|
Frequency Range |
450-520 / 698-960 / 1710-2700 / 3500-4000 MHz |
||||||||||
|
Coupling |
3 dB(4.8dB) |
5 dB |
6 dB |
7 dB |
8 dB |
10 dB |
13 dB |
15 dB |
20 dB |
30 dB |
|
|
Output Split (Main Loss) |
-2.05 dB |
-1.8 dB |
-1.35 dB |
-1.0 dB |
-0.7 dB |
-0.4 dB |
-0.2 dB |
-0.1 dB |
-0.1 dB |
-0.1 dB |
|
|
Dissipative Loss(dB) |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
0.3 dB |
|
|
Branch fluctuate (db) |
450-520 |
0/-1.2 |
0/-1.2 |
0/-1.2 |
+0.3/-1.2 |
+0.3/-1.2 |
+0.3/-1.2 |
±1.0 |
±1.0 |
±1.0 |
±1.6 |
|
698-960 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±1.6 |
|
|
1710-2700 |
±0.8 |
±0.7 |
±0.7 |
±0.7 |
±0.7 |
±0.8 |
±0.8 |
±0.8 |
±1.2 |
±2.0 |
|
|
3500-4000 |
+0.5/-1.5 |
+0.3/-1.5 |
+0.5/-1.5 |
±1.2 |
±1.2 |
+0.3/-1.5 |
±1.2 |
±1.2 |
±1.5 |
±2.5 |
|
|
VSWR |
698-2700 |
1.35:1 |
1.35:1 |
1.35:1 |
1.25:1 |
1.25:1 |
1.25:1 |
1.25:1 |
1.25:1 |
1.25:1 |
1.25:1 |
|
450-4000 |
1.5:1 |
1.5:1 |
1.4:1 |
1.35:1 |
1.3:1 |
1.3:1 |
1.3:1 |
1.3:1 |
1.25:1 |
1.25:1 |
|
|
Intermodulation |
≤-160dBc@2x43dBm (698-2700MHz) |
||||||||||
|
Power Rating |
300 W |
||||||||||
|
Impedance |
50 Ω |
||||||||||
|
Connector |
4.3-10/Female |
||||||||||
|
Weight(kg) |
0.23 |
||||||||||
|
Temperature Range |
-35~75ºC |
||||||||||
|
Applications |
Indoor/Outdoor Use , IP67 |
||||||||||
|
Product Drawing |
As Below |
||||||||||
