Product Description
The UHF Wideband Coaxial Isolator is a high-reliability RF component designed for the 300-400MHz frequency range. Featuring a clockwise signal direction and low insertion loss, it is an ideal choice for protecting active microwave components in Commercial and Space applications.
Application Scenarios
- Military Communications: Robust signal protection for UHF radio systems in demanding field operations.
- Aerospace Systems: High-isolation performance tailored for satellite and space-grade hardware.
- Broadcasting: Ensures signal integrity by preventing reflected waves from damaging high-power transmitters.
Technical Specifications
| Parameter | Specifications |
|---|---|
| Model No. | MNI-300-400-NF |
| Frequency Range | 300 - 400 MHz |
| Insertion Loss | ≤ 0.6 dB |
| Isolation | 18 dB Min |
| VSWR | ≤ 1.3 |
| Power Rating | 50W (CW) / 10W (RV) |
| Direction | Clockwise |
| Impedance | 50 Ohm |
| Connector Type | N-Female |
NOTE: All technical specifications can be modified as per customer requirements. Our R&D team supports full customization for specific wideband frequencies.
Frequently Asked Questions
- Q1: What is the significance of the "Clockwise" direction?
- A: The Clockwise direction defines the path the signal takes from the input to the output. Our engineering team can also provide counter-clockwise configurations upon request.
- Q2: Can this isolator handle more than 50W of power?
- A: The standard power rating is 50W CW. For higher power needs, we can provide custom technical specifications to match your system's power level.
- Q3: Is the N-Female connector the only option?
- A: While N-Female is common for these UHF Wideband applications, we offer OEM services for various connector types like SMA or DIN.
- Q4: Do you offer 24-hour engineer support?
A: Yes, you can contact our salesmen and engineers 24 hours a day for professional skills support and assistance with any project requirements.
Mechanical Drawing (mm)
