Product Name
Maniron 2G 3G 4G FCC certified Signal Booster Multi-band Cell Phone Signal Amplifier
Application
Boosting the mobile signal strength, increase mobile signal in building coverage.
Technical & Mechanical Specifications
tems
Uplink
Downlink
Frequency Range
Band 12
704 ~ 716 MHz
734 ~ 746 MHz
Band 13
776 ~ 787 MHz
746 ~ 757 MHz
Band 5
824 ~ 849 MHz
869 ~ 894 MHz
Band 4
1710 ~ 1755 MHz
2110 ~ 2155 MHz
Band 2
1850 ~ 1910 MHz
1930 ~ 1990 MHz
Output Power
10± 2dBm
15± 2dBm
Gain
60± 2dB
60± 2 dB
Ripple
Band 12
≤8 dB
≤8 dB
Band 13
≤8 dB
≤8 dB
Band 5
≤8 dB
≤8 dB
Band 4
≤8 dB
≤8 dB
Band 2
≤15 dB
≤15 dB
Max. Input Power Without Damage
-10 dBm
-10 dBm
Spurious Emission
9KHz~1GHz
≤-36 dBm
≤-36 dBm
1GHz~12.75GHz
≤-30 dBm
≤-30 dBm
ALC Active 20dB
≤2 dB
≤2 dB
Alarm
ALC not Active
—
Green
ALC Active 5~10dB
—
Orange
ALC Active 15~20dB
—
Red
Self-oscillation
—
Red Flashing
(Uplink OFF)
Time Delay
≤0.5 μs
≤0.5 μs
Power Supply
DC:5 V
Power Consumption
< 20 W
RF Connector
N-Female
Environment Conditions
IP40
Humidity
< 90%
Operating Temperature
-10℃ ~ +55℃
