7/16 DIN-Male RF coaxial Connector for 7/8" cable

DIN-Male RF Connector is Low VSWR and excellent impedance matching,supports-105/-120/-150dBc PIM Rating and Widely used in IBS projects.
  • Item NO.:

    MNC-7/8-DM
  • Product Orgin:

    China
  • Shipping Port:

    Shanghai/Ningbo/Shenzhen
  • Products Details

Product Name

DIN-Male RF coaxial connector (DC-3GHz,DIN male , Low VSWR)


Product Features

DIN-Male RF Connector for 7/8" cable coaxial Connector is Low VSWR and excellent impedance matching, supports-105/-120/-150dBc PIM Rating and Widely used in IBS projects



Technical &Mechanical Specifications

Model No.

MNC-7/8-DM

Interface

According to IEC 60169-4

Electrical

Characteristic Impedance

50 ohm

Frequency Range

DC-3GHz

Dielectric Withstanding Voltage

≥4000V RMS,50Hz,at sea level

Dielectric Resistance

≥10000M ohms

Contact Resistance

Center Contact≤1.0M ohms

Outer Contact≤0.30M ohms

VSWR

≤1.10

Mechanical

Durability

Mating cycles≥500

Material and plating

Body

Brass Ni or Tri-Alloy

Insulator

PTFE

Center Conductor

Phosphor Bronze or Ag

Coupling Nut

Brassi Ni

Temp

-40~+85


Mechanical Drawing (mm)

7/16 DIN-Male RF Connector

7/16 DIN-Male RF Connector

7/16 DIN-Male RF Connector












Leave Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
