800-2170MHz 50W Directional Coupler with SMA Female Connector For DAS IBS

800-2170MHz  50W directional coupler with SMA-Female Connector
  • Item NO.:

    OHQ-8002170-SMA
  • Product Orgin:

    China
  • Brand:

    Maniron
  • Shipping Port:

    Shanghai/Shenzhen/Guangzhou/Ningbo
  • Color:

    Sliver
  • Products Details

Product Name


50W Directional coupler  (800-2170MHz, SMA-F)


Product Features

◆ Wide Frequency Band 800-2170MHz

◆ 2G/3G/4G/LTE Coverage
◆ Low Insertion Loss
◆ Low VSWR
◆ Widely used for In-building Solutions

Technical & Mechanical Specifications

Part number (BO)



OHQ-8002170-SMA

Freq(MHz)

800-2170

Coupling(dB)

10

15

IL(dB)

1.0

0.4

Accuracy(dB)

±1.0

±1.0

Isolation(dB)

28

33

VSWR

1.25

Impedance

50 ohm

Connector

SMA-female

Power(W)

50W

Color

Grey

Temp(deg)

-30~+65

Humidity

5%-95%

Dimensions

See drawing


Mechanical Drawing
