Two way Directional Coupler 800-3700MHz N type with Low PIM

The function of the Two way Directional Coupler 800-3700MHz is to couple a part of the power as needed to a signal in a certain direction of transmission.
  • Item NO.:

    M2DC-837-xxdB-140-NF
  • Product Orgin:

    China
  • Brand:

    Maniron
  • Shipping Port:

    Shanghai/Guangzhou/Shenzhen
  • Color:

    Black
  • Products Details

Product name:

Two way Directional Coupler 800-3700MHz 6dB-40dB for 5G DAS IBS

Product Features:

◆Wide Frequency Bandfor 5G IBS BTS DAS

◆ 2G/3G/4G/LTE/5G Coverage

◆ Low VSWR &Insertion Loss

◆ Widely used for In-building Solutions

Technical &Mechanical Specifications

Part number



                    M2DC-837-xxdB-140-NF

                                                                                 xx refers to coupling value

Freq(MHz)

800-3700

Coupling(dB)

5

6

7

10

12

15

20

25

IL(dB)

INPUT1 /OUTPUT 1

≤2.2

≤2.0

≤1.5

≤1.0

≤0.8

≤0.7

≤0.5

≤0.4

INPUT 2/OUTPUT 2

≤3.1

≤2.8

≤2.4

≤2.0

≤1.8

≤1.7

≤1.5

≤1.4

Accuracy(dB)

INPUT 1

±1.5

±1.5

±1.5

±1.5

±1.5

±1.5

±1.6

±1.7

INPUT 2

±2.0

±2.0

±2.0

±2.0

±2.0

±2.0

±2.2

±2.2

Isolation(dB)

INPUT 1 / INPUT 2

≥20

OUTPUT1/OUTPU 2

≥20

INPUT VSWR

≤1.35

PIM(dBc)

≤-140dBc@2*43dBm 800-2700MHz

Impedance

50 ohm

Connector

N female connector

Power(W)

300W average

Color

Black

Operation Temp(deg)

-40~+55

Storage temp(deg)

-55℃~+85℃

Humidity

≤95%

Two way Directional Coupler 800-3700MHz
