-160dBc 600-6000MHz directional coupler 6--30dB 4.3-10 type

600-6000MHz directional coupler for IBS BTS DAS ,5dB/6dB/10dB/13dB/15dB/20dB/30dB Low VSWR, Low Insertion loss, Low PIM
  • Item NO.:

    MDC-6060-XX-41F-161(
  • Products Details

Product name

600-6000MHz rf directional coupler for 5G BTS DAS IBS


Product features

◆Wide Frequency Bandfor 5G IBS BTS DAS

◆ 2G/3G/4G/LTE/5G Coverage

◆ Low Passive Intermodulation

◆ Low VSWR &Insertion Loss

◆ High Isolation, Indoor outdoor Application

◆ Widely used for In-building Solutions


Technical &Mechanical Specifications

Model No.

MDC-6060-XX-41F-161(XX means coupling in dB)

Freq(MHz)

600-6000

VSWR

600-698≤1.40    698-2700≤1.30     2700-6000≤1.5

Attenuation(dB)

6

10/13

15

20

30

Insertion Loss(dB)

≤2.0

≤1.2

≤0.8

≤0.5

≤0.4

Accuracy(dB)

600-698±1.8

698-2700±1.5

2700-6000±1.8

600-698±2.2

698-2700±1.8

2700-6000±2.2

600-698±3

698-2700±2.5

2700-6000±3

600-698±3.2

698-2700±2.8

2700-6000±3.2

600-698±3.6

698-2700±3.

2700-6000±3.6

Isolation(dB)

600-698≤26

698-2700≤24

2700-6000≤18

600-698≤30/31

698-2700≤26/27

2700-6000≤22/24

600-698≤32

698-2700≤28

2700-6000≤25

600-698≤40

698-2700≤38

2700-6000≤32

600-698≤50

698-2700≤48

2700-6000≤42

PIM (dBc)

≤-161dBc@2*43dBm (698-2700)

Power(W)

200W

Impedance

50 ohm

Connector

4310-female

Color

Black-plated

Temp(deg)

-30~+65

Images


directional coupler 6dBdirectional coupler 6dB6dB directional coupler
