Customized New Product 791-960MHz Low Band-pass Filter with N female connector for IBS DAS

Band-pass Filter which covers from frequency 791-960MHz

Item NO.:
MNL-BF-960-NF
Product Orgin:
China
Brand:
Maniron
Shipping Port:
Shanghai/Shenzhen
Color:
Black or customized

Inquiry now

Products Details

Product Name

791-960MHz Band-pass Filter

Product Features

◆Compact, Low Weight bandpass cavity filter

◆High Reliability

◆Simple Installation

Technical &Mechanical Specifications

Model No.	MNL-BF-960-NF
Frequency Range	791-960MHz
VSWR	≤1.3:1
Attenuation	≥60dB@100-500MHz&1200-2000MHz
Input Power(max)	30W
Surface Finish	Black Paint
Port Connectors	N-Female
Net Weight	0.8 KG
Configuration	As Below

Product Pictures
