10W 400-470MHz Duplexer with N/BNC Female Connector

The MN-450X RF Duplexer is a compact, high-performance RF device designed for simultaneous transmit and receive operation in the UHF 400–470MHz band. With high isolation (≥75dB), low insertion loss, and stable VSWR, it effectively separates TX and RX signals while protecting sensitive radio equipment.

Item NO.:
MN-450X
Product Orgin:
China
Brand:
Maniron
Color:
Black

Inquiry now

Products Details

Product Name

10W UHF 400-470MHz Cavity Duplexer with N/BNC Female connector

Product Features

◆ Low Insertion Loss
◆ Low VSWR
◆ High Isolation
◆ Widely used for In-building Solutions

Technical & Mechanical Specifications

Model No.	MN-450X
Frequency Range	400-470MHz
VSWR	≤1.50
Bandwidth	±200KHz
Frequency Spacing	8-10MHz
Insertion Loss	≤1.5dB
Isolation	≥75dB
Maximum Input Power	10W
Normal Impedance	50Ω
Connector	N/BNC Female
Operating Temperature	-20 ~ +50℃
Weight	1.0kg
Dimensions	130×154×35(±0.5mm)
