Product Description
The Maniron 698-3800MHz Outdoor MIMO Log-periodic Antenna is a high-performance directional antenna designed for robust outdoor signal enhancement. Featuring a wide frequency band and high gain, it is engineered to provide stable and efficient connectivity across multiple generations of mobile networks (LTE/5G). Its MIMO (Multiple Input Multiple Output) capability ensures superior data throughput and signal reliability for modern telecommunication systems.
Application Scenarios
- Distributed Antenna Systems (DAS): Ideal for wide-band signal distribution in complex network environments.
- Outdoor Signal Boosting: High gain performance for long-distance reception in rural or fringe areas.
- LTE & 5G Infrastructure: Covers the 698-3800MHz range, supporting mainstream global frequency bands.
- MIMO Communication: Dual-polarization design for improved spectral efficiency and link stability.
Technical & Mechanical Specifications
| Parameter | Specifications |
|---|---|
| Frequency Range | 698-960 / 1710-2700 / 3300-3800MHz |
| Gain | 8 / 9 / 10dBi |
| VSWR | ≤ 2.0 |
| Horizontal Beamwidth | 65±15° / 58±10° / 55±10° |
| Vertical Beamwidth | 60±15° / 55±10° / 50±10° |
| PIM | -150dBc (2*20W) |
| Input Impedance | 50Ω |
| Polarization | ±45° |
| Max Power | 50W |
| Connector | 2*N Female |
| Lightning Protection | DC Ground |
| Antenna Dimension | 260*500mm |
| Mounting Pole | Ø38-Ø60 mm |
| Operating Temperature | -40～+70 °C |
Frequently Asked Questions
- Q1: What frequency bands does this antenna support?
- A: It supports a wide frequency range from 698-3800MHz, including 700MHz, 800MHz, 900MHz, 1800MHz, 2100MHz, 2600MHz, and 3500MHz bands.
- Q2: What is the benefit of the MIMO design?
- A: The MIMO design with ±45° polarization helps reduce interference and significantly improves data transmission speeds in 4G and 5G networks.
- Q3: Is this antenna suitable for extreme weather conditions?
- A: Yes, it is built for outdoor use with an operating temperature range of -40°C to +70°C and features integrated DC Ground lightning protection.
- Q4: How do I install this antenna?
- A: The antenna is designed for pole mounting and is compatible with mounting poles ranging from Ø38mm to Ø60mm in diameter.
DAS Layout
